Description
Technical Specification
| Engine | |
|---|---|
| Type | Air cooled, 4 - stroke cylinder OHC, Self Start |
| Displacement | 124.7 cc |
| Max. Power | 8 kW @ 7500 revolutions per minute |
| Max. Torque | 10.6 Nm @ 6000 revolutions per minute |
| Bore x Stroke | 52.4 x 57.8 mm |
| Fuel System | Advanced Programmed Fuel Injection |
| Transmission & Chassis | |
|---|---|
| Clutch | Multi Plate Wet |
| Gear box | 5 Speed Constant Mesh |
| Frame | Tubular Diamond |
| Suspension | |
|---|---|
| Front | Telescopic Hydraulic Shock Absorbers |
| Rear | 5-step Adjustable Hydraulic Shock Absorbers |
| Brakes | |
|---|---|
| Front Brake Disc | 240mm |
| Front Brake Drum | 130mm |
| Rear Brake Drum | 130mm |
| Wheels & Tyres | |
|---|---|
| Front Tyre | 80/100-18 (Tubeless) |
| Rear Tyre | 90/90-18 (Tubeless) |
| Electricals | |
|---|---|
| Battery | MF Battery, 12V - 4Ah |
| Head Lamp | 12 V - 35 / 35 W (Halogen Bulb), Trapezoidal MFR |
| Tail/Stop Lamp | 12V -5 / 10W - MFR |
| Turn Signal Lamp | 12V - 10W x 4 - MFR |
| Dimensions | |
|---|---|
| Length | 2042 mm |
| Width | 740 mm |
| Height | 1102 mm |
| Saddle Height | 799mm |
| Wheelbase | 1273 mm |
| Ground Clearance | 180 mm |
| Fuel Tank Capacity | 12 Litre |
| Kerb Weight | 123 kg (Disc) | 122 kg (Drum) |
Nexus Blue
Heavy Grey
Glaze Black
Candy Blazing RedSELF START DRUM BRAKE ALLOY WHEEL - FI - ₹72,450
