Description
Technical Specification
| Engine | |
|---|---|
| Type | Air-cooled, 4-stroke Single Cylinder OHC |
| Displacement | 110.9 cc |
| Max. Power | 6.0 kW (8 BHP) @ 7000 Revolutions per Minute (RPM) |
| Max. Torque | 8.7 Nm @ 5500 revolutions per minute (RPM) |
| Compression Ratio | 9.5:01 |
| Starting | Electric Start / Kick Start |
| Ignition | FI (Fuel Injection) |
| Transmission & Chassis | |
|---|---|
| Clutch | Dry Automatic Centrifugal Clutch |
| Suspension | |
|---|---|
| Front | Bottom Link with Spring-loaded Hydraulic Damper |
| Rear | Swing arm with spring loaded hydraulic dampers |
| Brakes | |
|---|---|
| Front Brake | Internal Expanding Shoe Type (130 mm) |
| Rear Brake | Internal Expanding Shoe Type (130 mm) Integrated Braking System (IBS) |
| Wheels & Tyres | |
|---|---|
| Front | 90/100 - 10-53 J (Tubeless) |
| Rear | 90/100 - 10-53 J (Tubeless) |
| Electricals | |
|---|---|
| Battery | 12V - 4Ah ETZ-5 MF-Battery |
| Head Lamp | 12V-35W/35W. Halogen Bulb. Multi-Focal Reflector |
| Tail/Stop Lamp | 12V - 5/21W Multi-Focal Reflector Type |
| Turn Signal Lamp | 12V-10W x 4 nos. (Multi-Focal Reflector-Clear Lens-Amber Bulb) |
| Dimensions | |
|---|---|
| Length | 1769 mm |
| Width | 704 mm |
| Height | 1161 mm |
| Wheelbase | 1238 mm |
| Ground Clearance | 155 mm |
| Fuel Tank Capacity | 4.8 Litre |
| Kerb Weight | 106 kg |
